Additional information
Standards
SAE J516
Fitting Shape
90° Swept
Connection Size 1 (Fraction Inch)
1-1/16 in
Connection Size 2 (Fraction Inch)
3/4 in
Connection Size 2 (Metric)
19 mm
Connection Type 1
SAE
Connection Type 2
Crimp
Connection Gender 1
Female
Connection Gender 2
Genderless
For Hose Dash Size
-12
Termination Dash Size
-12
For Hose Inside Diameter (Fraction Inch)
3/4 in
For Hose Inside Diameter (Metric)
19 mm
Thread Size 1 (Inch)
1-1/16-14
Cutoff Size (Metric)
62 mm
Nut Hex Size 1 (Metric)
32 mm
Drop Length (Metric)
58 mm
Seated Angle (°)
45 °
Inside Diameter (Metric)
15 mm
