Additional information
Standards
SAE J516, ISO 12151-5
Fitting Shape
Straight
Connection Size 1 (Fraction Inch)
1-3/16 in
Connection Size 2 (Fraction Inch)
3/4 in
Connection Size 2 (Metric)
19 mm
Connection Type 1
JIC
Connection Type 2
Crimp
Connection Gender 1
Male
Connection Gender 2
Genderless
For Hose Dash Size
-12
Termination Dash Size
-14
For Hose Inside Diameter (Fraction Inch)
3/4 in
For Hose Inside Diameter (Metric)
19 mm
Thread Size (Inch)
1-3/16-12
Working Pressure (psi)
3500 psi
Cutoff Size (Metric)
44.5 mm
Stem Hex Size (Metric)
32 mm
Seated Angle (°)
37 °
Inside Diameter (Metric)
15 mm
