Additional information
Fitting Shape
Straight
Connection Size 1 (Metric)
M45
Connection Size 2 (Fraction Inch)
1 in
Connection Size 2 (Metric)
25 mm
Connection Type 1
Metric
Connection Type 2
Crimp
Connection Gender 1
Male
Connection Gender 2
Genderless
For Hose Dash Size
-16
Termination Dash Size
-45
For Hose Inside Diameter (Fraction Inch)
1 in
For Hose Inside Diameter (Metric)
25 mm
Thread Size 1 (Metric)
M45 X 1.5
Cutoff Size (Metric)
39.7 mm
Stem Hex Size (Metric)
46 mm
Seated Angle (°)
24 °
Inside Diameter (Metric)
20 mm
Tube Outside Diameter (Metric)
34 mm
