Additional information
Fitting Shape
90° Swept
Connection Size 1 (Fraction Inch)
3/4 in
Connection Size 2 (Fraction Inch)
3/4 in
Connection Size 2 (Metric)
19 mm
Connection Type 1
Flange
Connection Type 2
Crimp
Connection Gender 1
Female
Connection Gender 2
Genderless
For Hose Dash Size
-12
Termination Dash Size
-12
For Hose Inside Diameter (Fraction Inch)
3/4 in
For Hose Inside Diameter (Metric)
19 mm
Working Pressure (MPa)
41.4 MPa
Working Pressure (psi)
6000 psi
Cutoff Size (Metric)
63.5 mm
Drop Length (Metric)
63.5 mm
Flange Diameter (Metric)
41.3 mm
Inside Diameter (Metric)
14 mm
