Additional information
Standards
DIN20066, DIN3865
Fitting Shape
Straight
Connection Size 1 (Metric)
M26
Connection Size 2 (Fraction Inch)
1/2 in
Connection Size 2 (Metric)
12 mm
Connection Type 1
Metric
Connection Type 2
Crimp
Connection Gender 1
Female
Connection Gender 2
Genderless
For Hose Dash Size
-08
Termination Dash Size
-26
For Hose Inside Diameter (Fraction Inch)
1/2 in
For Hose Inside Diameter (Metric)
12 mm
Thread Size 1 (Metric)
M26 X 1.5
Working Pressure (psi)
5100 psi
Cutoff Size (Metric)
30 mm
Stem Hex Size (Metric)
32 mm
Seal Type
O-Ring
Seated Angle (°)
24 °
Inside Diameter (Metric)
12 mm
Tube Outside Diameter (Metric)
18 mm
