Additional information
Fitting Shape
45° Swept
Connection Size 1 (Fraction Inch)
1-1/4 in
Connection Size 2 (Fraction Inch)
1 in
Connection Size 2 (Metric)
25 mm
Connection Type 1
BSP
Connection Type 2
Crimp
Connection Gender 1
Female
Connection Gender 2
Genderless
For Hose Dash Size
-16
Termination Dash Size
-20
For Hose Inside Diameter (Fraction Inch)
1 in
For Hose Inside Diameter (Metric)
25 mm
Thread Size (Inch)
1-1/4-11
Cutoff Size (Metric)
90.6 mm
Nut Hex Size (Metric)
50 mm
Drop Length (Metric)
39 mm
Seal Type
O-Ring
Seated Angle (°)
60 °
Inside Diameter (Metric)
19 mm
