Additional information
Fitting Shape
90° Elbow
Connection Size 2 (Fraction Inch)
3/8 in
Connection Size 2 (Metric)
10 mm
Connection Type 2
Hose Barb
Connection Gender 2
Male
For Hose Dash Size
-06
Termination Dash Size
-04
For Hose Inside Diameter (Fraction Inch)
3/8 in
For Hose Inside Diameter (Metric)
10 mm
Drop Length (Metric)
40 mm
Inside Diameter (Metric)
4 mm
Outside Diameter (Metric)
10 mm
Center to End Size 1 (Metric)
30.5 mm
