Additional information
Standards
SAE J516, ISO 12151-1
Fitting Shape
Straight
Connection Size 1 (Fraction Inch)
9/16 in
Connection Size 2 (Fraction Inch)
3/8 in
Connection Size 2 (Metric)
10 mm
Connection Type 1
ORFS
Connection Type 2
Crimp
Connection Gender 1
Female
Connection Gender 2
Genderless
For Hose Dash Size
-06
Termination Dash Size
-04
For Hose Inside Diameter (Fraction Inch)
3/8 in
For Hose Inside Diameter (Metric)
10 mm
Thread Size (Inch)
9/16-18
Working Pressure (MPa)
68.9 MPa
Working Pressure (psi)
10000 psi
Cutoff Size (Metric)
29 mm
Stem Hex Size (Metric)
17 mm
Inside Diameter (Metric)
7 mm
